Series 9100 Submersible Non-Clog Pumps

Yeomans Series 9100 submersible pumps are among the finest available in today’s wastewater industry. Heavy-duty industrial quality, superior design features and a wide range of materials and options combine to provide the user with the ultimate in long service life and system reliability.

 Product Overview:

  • IP68 motor protection
  • Available with third-party (F.M) explosion-proof listing
  • Motors designed and rated per NEMA MG-1 and IEEE standards
  • “Easy-Lift” Guiderail Systems
  • Free-Standing units for portable service
  • Capacities to 10,000 USGPM (2,271 m3/hr)
  • Heads to 300 feet (91m)
  • Temperatures to 187 F (90 C)
  • Pressures to 200 PSIG (1378 kPa)
  • Discharge Sizes from 4" (100mm) to 14" (356mm)
  • Solids (sphere size) to 6" (152mm)
  • Standard "Type 21" mechanical seals for low-cost and quick availability from local sources
  • "Solid-Block" seal ring design assures long life and reliability under upset conditions
  • Dual moisture detection probes to eliminate false alarms
  • Terminal Board cable connection for quick replacement of the cap/cable assembly
  • Epoxy-potted cable entry prevents moisture from entering the motor via the power/control cables
  • Thermal switches in motor windings for over-temperature protection
  • All sizes available with special pump-end materials of construction to meet the specific application requirements
